GSM: 850/ 900/ 1800/ 1900 MHz
GPRS: Class12, TCP/ IP build in GSM Module
GPS: SIRF Star III
GPS Channels: 20
Tracking sensitivity: -158dBm
Acquisition sensitivity: -144dBm
Locating time cost: Hot start: <2 sec(open sky)
Warm start: <15 sec
Cold start: <38 sec(open sky)
Antenna: Built-in GSM quad band antenna, GPS high gain antenna.
Battery: 450mAh
Monitoring range: Speed accuracy 0.1 meter/second ;Position accuracy:10 meter, 2D RMS
Voltage input range: 8-36 VDC
LED indicator: Three LED indicator:
GPS-blue, GSM-green, Power-red
Dimensions: 10.1×5×2.4 CM
Weight: 88g
Application environment: Operating temperature: -25
℃ to +70℃
Operating humidity: 5% to 95% non-condensing
